STYLISTIC ST 5000 Series
Free your life
with the newest
Fujitsu STYLISTIC ST5000 and ST5000D Series Tablet PC
Think flat. Think thin. Think bigger.
Think about a PC roughly the size and shape of a thick magazine. Think
about scribbling notes on it, editing documents on it, sending emails or
wirelessly shared files on it—all with the stroke of a pen. It's an
interesting concept, isn't it? A PC you can tuck under your arm, slip
discreetly onto a conference table, or hold like a clipboard as you walk
through a warehouse, a field or a corporate corridor.
The latest evolution in Tablet PC
technology, the Stylistic ST5000 Series Tablet PC, delivers an
unsurpassed level of productivity and performance. This innovative sytem
based on over a decade of design, engineering, and manufacturing
expertise, improves your business productivity with proven quality and
reliability from the undisputed leader in pen computing.
Improving on the award-winning Tablet PC, the Fujitsu
Stylistic® ST5000 Tablet PC offers technology advancements to keep pace
with the versatility of today's mobile professionals. With its added
security features such as an integrated fingerprint sensor, dedicated
Smart Card reader slot, imbedded Trusted Platform Module, security
application panel, and a Kensington lock slot; your data and assets are
more secure. In addition, new features such as display selections with
up to 180° viewing angles and a built-in dual mic array with noise
cancellation software empowers you to work wherever your work takes you.
The T5000 includes Intel® Centrino™ Mobile Technology with
a choice of three industry-leading display options - ST5020/ST5022 -
12.1" indoor display, optional 12.1" indoor/outdoor display or ST5021-
10.4" indoor/outdoor display.
The T5000D includes Intel® Pentium® M Processor Ultra Low
Voltage 733 with a choice of three industry-leading display options.
|
|
Built-in wireless access and the latest Intel® Centrino™ mobile
technology means you can instantly input and access information
whenever, wherever needed.
Flexible Form Factor
With the revolutionary thin and light slate form factor, the Stylistic®
ST5000 Tablet PC provides the freedom to be more productive. The system
is weight-balanced so it can be carried comfortably in either portrait
or landscape mode. You can now compute on the go with ease, for longer
periods of time.
The slate is also the most flexible form factor. Use it alone like a
notepad with minimal weight and bulk, or add a keyboard for a more
familiar notebook feel. The optional portfolio or attaché cases make
keyboard use even easier by providing a convenient easel stand. With the
optional tablet dock, the system can be transformed into a complete
desktop solution. The dock supports both Portrait and Landscape modes,
tilts for better viewability and pen use while docked, and allows
immediate undocking, letting you grab and go without rebooting.
Quality and Reliability
The tight interaction between Fujitsu design, engineering, manufacturing
and service support creates some of the highest quality products offered
in the PC market. In a time when most PCs are assembled by third-party
vendors, Fujitsu takes pride in its own world-class design and
manufacturing capabilities.
Active Digitizer
In combination with a special pen, the electromagnetic
(active) digitizer allows for a more accurate pen-driven input. The
digitizer allows both hovering and variable pressure effects for smooth
inking, increasing the overall user experience.
Display
Indoor (Transmissive) display—Viewability on this screen is designed for
typical office and home work environments. The bright 12.1" XGA LCD
display produces a high contrast ratio and complements applications that
use high definition graphics. This display is like any typical notebook
display.
One-touch Application Launch
Buttons
There are six intuitive and easy-to-use buttons that enable you to
launch or navigate within applications. With one-touch launch buttons
you can easily launch your email or instantly rotate your screen
orientation. Each of these buttons also has secondary functions and two
of the secondary functions are user-programmable. There are also four
navigation buttons that provide up to eight navigation functions for
increased efficiency.
Added Durability
With its sleek design and solid feel, the Stylistic® ST5000 Tablet PC
not only looks great, but will also stand up to the rigors of travel and
everyday use. The magnesium alloy lower case provides significant
protection over plastic casings found on other Tablet PCs. In addition,
the hard drive is shock-mounted to protect your data. Fujitsu
craftsmanship and quality are included as a standard feature on our
Stylistic® ST5000 Tablet PC.
Custom Configurable
With custom configuration available on all Stylistic® ST5000 Tablet PC
models, you may either purchase your choice of recommended configuration
or configure as-you-need-it with only the components that fit your needs
and budget.
Less than 1" thick, lightweight (3.4lbs) and, with its great high-tech
design, the STYLISTIC ST5000 Series Tablet PC is perfect for working
while standing and walking.
|
STYLISTIC |
ST5020 |
|
Processor |
Intel® Pentium M 1.1
GHz
Ultra Low Voltage |
Microsoft Windows XP
Tablet PC Edition |
Yes |
| System
Memory |
256 MB –
2 GB |
| LCD
viewable |
Bright
indoor |
Intel®
Centrino™
Mobile Technology Platform |
Yes |
Processor
Intel®
Pentium® M Processor Ultra Low Voltage 733 (1.10 GHz, 2
MB L2 cache, 400 MHz FSB)
Display
12.1" XGA LCD indoor viewable
display with 160° wide viewing angles;
Optional 12.1" XGA LCD indoor/outdoor viewable display with 160°
wide viewing angles
Memory
Two DIMM slots available; upgrade with 256 MB, 512 MB SDRAM, or 1
GB
maximum memory to 2 GB (1 GB x 2)
Digitizer
Electromagnetic (active), Wacom
Pen
Pen
Electromagnetic (active) – no battery required, Wacom pen
Hard disk drive
80, 60 GB or 40 GB ATA 100, shock-mounted hard drive
VRAM
Intel 855GME integrated UMA graphics with dynamic video memory
technology; supporting up to 64 MB (shared with system memory)
Audio
Realtek ALC202 with wavetable, 3D effect, and 3D positioning;
Dolby® Headphone
Utility to emulate realistic surround sound using conventional
stereo headphones on DVD
models; built-in microphone; headphone, microphone, and stereo
line-in jacks
Communications
Multinational 2 56K3 V.90 modem, 10/100/1000 Base-T/TX Ethernet,
and Intel® PRO/Wireless 2100 (Wi-Fi certified 802.11b); diversity
antenna
Interfaces
2 USB 2.0 ports
Infrared port (IrDA 1.1-compatible, 4 MBps)
External monitor connector
Modem (RJ-11) jack
Ethernet (RJ-45) jack
IEEE 1394 connector
Wireless IR keyboard receivers
System interface connector
Security
Trusted Platform Module
(TPM); dedicated Smart Card reader slot; biometric fingerprint swipe
sensor; Fujitsu Security Application Panel; Kensington lock slot
|
Battery
Lithium ion battery 10.8V;
6-cell, 4400mAh or
9-cell 6600mAh; battery life up to 8 hours (target), application
dependentAC Adapter
Auto-sensing 100-240V 50/60Hz DC 16V/3,75A
Power Management
ACPI 2.0
Dimensions and weight
Standard battery ; 12.77"(h) x 8.66"(w) x .82-.88"(d); Approximately
3.5 lbs.
High-capacity battery ; 13.5"(h) x 8.66"(w) x .82-.88"(d);
Approximately 3.9 lbs
Operating system
Microsoft Windows XP Tablet PC Edition Fujitsu Tablet PCs use genuine Windows Operating
Systems
Software
Microsoft®
Office OneNote™ 20035, Fujitsu Display Controls,
Fujitsu Hot Key Utility, Fujitsu Security Application Panel, Adobe®
Reader®, MS Reader, Softex OmniPass
Environmental
Operating Temperature
(with power management): 41° to 95°F (5° to 35°C);
Humidity: 20% to 85% (non-condensing)
Non-Operating Temperature: 5° to 140°F (-15° to 60°C);
Humidity: 8% to 85% (non-condensing)
Warranty
1 year, upgradeable to 3 years limited warranty, country-specific terms
Accessories
Portfolio Case, Attaché Case, Bump Case, Harsh Environment Case,
Battery Charger, 4400mAh/6600mAh Battery Pack, Replacement Stylus,
Screen Protector, AC Adapter, Auto Adapter, Pen Tether, External
3.5-inch Floppy Disk Drive, 256 MB, 512 MB or 1024 MB DDR SDRAM
Memory Module, USB Keyboard, Wireless IR Keyboard, Tablet Dock with
DVD or DVD/CDRW-combo drive
Tablet Dock
3x USB ports (2.0), 10/100/1000 Base-T Ethernet (RJ-45), DC-in
jack, Stereo line-out jack, IEEE1394, VGA, DVD-/CD-ROM drive
optional in modular bay: 8x/24x/24x/10x DVD/CD-R/RW combo drive
Wireless technologies
Import and usage according to country-specific regulations
|
The Stylistic ST5000D supports an optional 802.11a+b/g wireless LAN.
802.11g is the next-generation in wireless LAN technology and offers
transfer rates of up to 54 Mbps (nearly five times faster than the
802.11b standard).
Stylistic ST5020 Tablet PC
FPCM35181
•Intel® Pentium® M Processor Ultra Low Voltage 733 (1.10 GHz, 2 MB L2
cache, 400 MHz FSB) •Microsoft® Windows® XP Tablet PC Edition 2005•12.1"
XGA TFT with indoor wide view display•512 MB DDR 333 SDRAM memory
•60 GB 4200 rpm hard drive¹•Built-in multinational² 56K³ V.90 modem and
10/100/1000 Base-T/TX Ethernet•Built-in Intel® PRO/Wireless 2200BG
Network Connection (802.11b/g)
•Bluetooth wireless PAN
•Integrated Fingerprint reader, imbedded TPM, dedicated Smart Card slot,
Fujitsu Security Application Panel
•Dual mic array with IntelliSonic™ noise cancellation software
•Standard 6-cell (4800 mAh) battery
•Microsoft® Office OneNote® 20034
•One-year International Limited Warranty
•M-Code FPCM35181
|
Stylistic ST5022 Tablet PC
FPCM35191
•Intel® Pentium® M Processor Ultra Low Voltage 733 (1.10 GHz, 2 MB L2
cache, 400 MHz FSB)
•Microsoft® Windows® XP Tablet PC Edition 2005
•12.1" XGA TFT with indoor/outdoor wide view display
•256 MB DDR 333 SDRAM memory
•40 GB 4200 rpm hard drive¹
•Built-in multinational² 56K³ V.90 modem and 10/100/1000 Base-T/TX
Ethernet
•Built-in Intel® PRO/Wireless 2200BG Network Connection (802.11b/g)
•Integrated Fingerprint reader, imbedded TPM, dedicated Smart Card slot,
Fujitsu Security Application Panel
•Dual mic array with IntelliSonic™ noise cancellation software
•Standard 6-cell (4800 mAh) battery
•Microsoft® Office OneNote™ 20034
•One-year International Limited Warranty
•M-Code FPCM35191 |
Stylistic ST5020 Tablet PC
FPCM35182
•Intel® Pentium® M Processor Ultra Low Voltage 733 (1.10 GHz, 2 MB L2
cache, 400 MHz FSB)
•Microsoft® Windows® XP Tablet PC Edition 2005
•12.1" XGA TFT with indoor wide view display
•256 MB DDR 333 SDRAM memory
•40 GB 4200 rpm hard drive¹
•Built-in multinational² 56K³ V.90 modem and 10/100/1000 Base-T/TX
Ethernet
•Built-in Intel® PRO/Wireless 2200BG Network Connection (802.11b/g)
•Integrated Fingerprint reader, imbedded TPM, dedicated Smart Card slot,
Fujitsu Security Application Panel
•Dual mic array with IntelliSonic™ noise cancellation software
•Standard 6-cell (4800 mAh) battery
•Microsoft® Office OneNote® 20034
•One-year International Limited Warranty
•M-Code FPCM35182
|
STYLISTIC ST Series
Experience
Fujitsu Siemens Computers has been designing,
manufacturing and marketing pen tablet PCs for more than a decade and is
recognized as the undisputed leader in the pen tablet PC market.
We have learned a great deal about the technology and even
more about the usage patterns of pen tablet PC users. We apply this
knowledge and expertise to all our products and customer solutions.
Fujitsu Siemens Computers, a pioneer in the tablet market,
designed and manufactures its newly announced STYLISTIC ST4000 Tablet PC
series.
The tight interaction between our design, manufacturing,
and service engineers creates some of the highest quality products offered
in the PC market. In a time where most PCs are produced under OEM
agreements, we take pride in having our own world-class design and
manufacturing capabilities.
Thin and sleek
With its 2.2 cm thickness and being close to an A4 size,
weighing only 1.4 kg and its great high-tech design, the STYLISTIC ST4000
series is perfect for working while standing and walking.
For reliable mobile field usage
The Tablet PC has a robust design and a battery life up to
5 hours.
An integrated metal frame strengthens the unit as well as
it helps dissipating heat. The hard disk is mounted on shock absorbers for
a real unit usable on the move.
Microsoft Windows XP Tablet PC Edition
The Tablet PC
provides the full power and functionality of today’s notebook PCs – with
no sacrifices. Windows XP Tablet PC Edition is a superset of Windows XP
Professional
|
|
4000
Series
|
Processor Intel Pentium III 800 MHz -
M with SpeedStep technology; 512KB L2 Cache; 133MHz system bus speed
or
Ultra Low Voltage Mobile Intel(R) Pentium(R) III
Processor 933MHz - M with Enhanced Intel(R)
SpeedStep(R) Technology
BIOS
Phoenix BIOS; 8Mbit, Flashable
Display
Indoor/Outdoor 10.4" XGA TFT Reflective FL (ST4121) or
Indoor 10.4" XGA TFT Transmissive (ST4120)
Memory
256MB or 512MB SDRAM on board; 256MB and 512MB upgrade modules available; Total maximum of 768MB
Digitizer
Electromagnetic (Active), Wacom, for ST4110 Resistive (Passive)
for ST4110P
Pen
Electromagnetic (Active) – no battery required, Wacom Passive for
ST4110P
Hard disk drive
20GB or 40GB Ultra DMA with SMART Support, shock-mounted hard
disk drive
VRAM
Intel 830M Integrated UMA Graphics with Dynamic Video Memory
Technology. Supporting up to 48MB (shared with system memory)
Audio
SigmaTel STAC9767 with wavetable, 3D effect, and 3D positioning;
Dolby Headphone Utility to emulate realistic surround sound using
conventional stereo headphones on DVD models; built in microphone;
headphone, microphone and stereo line-in jacks
Communications
Ethernet and modem (standard); built-in Wireless LAN
(802.11b -- optional)
Ports
Two USB, Infrared port (IrDA 1.1-compatible,
4Mbps), external monitor and docking connector
PC Card Slots
One Type I or Type II PC card slot
|
Application buttons & 2 Navigation
buttons Allows to quickly launch pre-defined applications and utilities
by pressing a button
Security
Kensington Lock support
Battery
6-cell or 9-cell Lithium ion battery
AC Adapter
Auto-sensing 100-240V 50/60Hz DC 16V/3,75A
Power Management
ACPI 2.0
Dimensions and weight
8.66" (W) x 11.86" (H) x 0.82 - 0.88" (D) / 3.2 lbs (with
standard six-cell battery)
Operating system
Microsoft Windows XP Tablet PC Edition for ST4110
Fujitsu Siemens Computers Tablet use genuine Windows Operating
Systems
www.microsoft.com/piracy/howtotell
Environmental
Operating Temperature (with power management): 5º to 35ºC (41º to
95ºF); Humidity: 20% to 85% (non-condensing)
Non-Operating Temperature: -15º to 60ºC (5º to 140ºF);
Humidity: 8% to 85% (non-condensing)
Warranty
country-specific terms
Accessories
Portfolio Case, Slip Case, Battery Charger, 4000mAh Battery Pack,
Replacement Stylus, Screen Protector, AC Adapter, Auto Adapter, Pen
Tether, External 3.5" Floppy Disk Drive, 256 or 512MB SDRAM Memory
Module, USB Keyboard, Wireless IR Keyboard, Tablet Dock, WLAN (built
in optional)
Tablet Dock
3x USB port, 10/100 Base-T Ethernet (RJ-45), DC-in jack, Stereo
line-out jack, CD-ROM drive or combined CD-RW/ DVD drive; CRT;
IEEE1394
Wireless technologies
Import and usage according to country-specific regulations
|
Pricing and Availability
The Stylistic ST Series Tablet PC is currently shipping and
sold through the Fujitsu direct sales force, Web site and channel
partners. Pricing starts at $1,999(3) for a base configuration.
Models with the indoor/outdoor display start at $2,199(3). Users
can choose from several recommended configurations or they can
customize the Tablet PC using the Fujitsu Configure To Order (CTO)
program.
Service and Support
The Fujitsu Stylistic ST Series Tablet PC is backed by a
three-year or one-year International Limited Warranty for U.S. and
Canadian customers. The International Limited Warranty includes
technical support, 24 hours a day, seven days a week(4). In
addition, users can add Fujitsu Premium Care Service Plans, which
include an on-site service or a screen protection plan.All rights, including rights created by patent grant or
registration of a utility model or design, are reserved. Delivery subject to
availability; right of technical modifications reserved.
All hardware and software names used are trade names or
trademarks of their respective manufacturers.
|
|
|
|
|
2000-2009
