Tatung 910

Tablet PC runs Microsoft Windows XP Tablet PC Edition and features the capabilitles of current laptops and the ability to run Windows-based application,with extends of digital pen and speech capabilities, which allows you to use the PC in a more simplified way anywhere you want it.

Tablet PC is positioned as "the next major evolution of the laptop" since it combines the simplicity of paper with the power of the PC, possesses the rich features of a notebook with the simplicity of a pen, serves as a natural form of computing but performs an adaptable and ergonomic form factor and facilitates functionality, portability, usability and connectivity.

To return to Tatung's main page, click here

Product Features

Microsoft Windows XP Tablet PC Edition,featuring Handwriting & Voice recognition.

866MHz Intel PIII Tualatin Ultra Low Voltage Mobile Processor ,up to 933MHz.

Core logic Chipset - Intel 830MG.

256MB PC133 SDRAM System Memory ,up to 768MB.

2.5'' 20GB HDD.

10.4"Toshiba XGA LCD Panel.

WACOM Electromagnetic Digitizer + stylus.

EEE 802.11b V.90 Modem ,build in 10/100 Ethernet.

External COnnectors:USB 1.1 Type Ax2;VGA Out,Headphones Out, Microphone In

IEEE 1394,10/100 Ethernet,V.90 Modem,Docking station interface.

Li-Lon 4 cell Battery Pack which can run 3.5 hours.

Li-Lon 8 cell Battery Pack which can run 7- 8 hours.

Product Specifications

Processor	Ultra Low Vottage Mobile Intel	Right side	User Control
	Pentium III	Power / Suspend	Buttons
	Processor - M,866MHz,Speed Step	Screen Rotation
	Supported,up to 933MHz	Escape
		Fn
Core Logic	Intel 830MG	Enter
Graphics	Integrated within 830MG core logic	4-way pad(up,down,left,right)
	Landscape and portrait modes-	left side:
	software controlled	Security(Ctrl+Alt+Del)
		Hot1
Display	10.4"XGA TFT LCD (1024x768)	Brightness Up
		Brightness Down
Digitizer	Electromagnetic Digitizer	Rear side
	Stylus included	System Reset(with hole)
System Memory	256MB PC133 SDRAM solded directly on MB	Support USB 1.0.VGA,10/100BaseTx,DC in ,CD ROM	Docking Station Interface
	One SODIMM user upgradeable
		ACPI S0,S1,S3,S4 and S5	Power
Audio	AC-97 Rev2.1 compliant	ACPI 2.0 Compatible	Management
	Integral speaker
	Integral full duplex microphone	Power/Suspend	User
	Integral speakers	Battery Status	Indicators
		HDD access
Networking/	10/100 Ethernet on MB and
Communcations	802.11b/V.90 via internal mini-PCI module	12VDC @ 50W	AC Power
		World-wide EMI and safety approvals	Adapter
Mass Storage	20GB 2.5" x 9.5 mm,user removable
		1.4kg	Weight
Expansion	CardBus Type II with hot insertion	288(L)x252(W)x25.8(H)mm	Dimension
	and removal Compact Flash
	(ships with CF+ Type II PCMCIA dummy card)	Windows XP Tablet Edition	Operating
		Supported	System
		Note Taking	Application
Battery Pack	Lithium ion(7.4V,3.900mAh)	Ink Annotation
	3.5 hours battery life	MS Reader
	Delachable and user inter-changeable	Ink & Handwriting
	Lithium ion optional(7.4V,3.900mAh)	Speech Recognition
Battery Charging	2.5 hours (non-active)	On-screen Keyboard
Time	3.5 hours (active)
