Scribbler Specifications: |
|
|
Processor
|
Intel Pentium – M ULV
Centrino |
|
CPU Speed |
1.3
GHz |
|
Chipset |
Intel
GMCH – M 855 GM chipset |
|
Graphics Chip Internal |
32MB
Intel 8285X GM/GME Graphics Controller |
|
PC Card Controller |
PCMCIA x 1 |
|
Audio |
Realtek AC’97 Audio |
|
System Storage |
20 GB - 60G |
|
System Memory |
256 MB -768MB |
|
Display |
12.1”
XGA TFT 32-bit color Toshiba |
|
Digitizer |
WACOM
PWB-A560-A |
|
Fingerprint Sensor |
AuthenTec AES3500 TruePrint Sensor |
|
Networking |
Built-in IEEE 802.11b/g, 10/100 Ethernet, 56K Modem |
|
Power Management |
Sleep
and Hibernation |
|
Power Mgmnt Modes |
ACPI
2.0 Compatible |
| Light Sensor |
Screen brightness
automatically adjusts to surrounding light |
|
LED Indicators |
Power
On/Off Indicator, Battery Status, HDD Active, Wi-fi Connectivity |
|
External Connectors |
VGA
Out, IEEE1394, USB 2.0 x 2, Headphone Output x1, Microphone Input x
1,AC/DC
Power Jack, RJ-11, RJ-45, Infrared SMC IrCC Fast port, PCMCIA
slot,Keyboard/Mouse Base,
Docking
Station port |
|
MIC |
Internal x 1 |
|
Speaker |
Internal x 2 |
|
Buttons |
Power
On/Off, Security, Start, Journal, Keyboard, Rotate, Esc, Function,
Wireless, Direction Ball + Enter |
|
Battery Pack |
Super
Polymer Lithium Ion 70 Whr |
|
Battery Charging Time |
5
hours 15 min ( Computer off mode) |
|
Dimension |
With
keyboard/mouse attached: 11.96” x 9.17” x 1.0” |
| |
Without keyboard/mouse attached: 11.96” x 9.16” x 0.75” |
|
Weight |
With
keyboard/mouse attached: 4.1 lbs |
| |
Without keyboard/mouse attached: 3.1 lbs |
|
Operating System |
Microsoft® Windows® XP Tablet PC Edition |
| |
|
|
Software Bundle: |
|
Included Software
• Alias Sketchbook (Full Version)
• Corel Grafigo (Full Version)
• Farstone Virtual Drive Lite (Full Version)
• Adobe Acrobat Reader 5.1 (Full Version)
• Note Taking
• Ink Annotation
• MS Reader
• Speech Recognition
• On-screen Keyboard
• Franklin Covey TabletPlanner (Trial Version) |
 |
|
Docking
Station
• 90° Rotation (Support screen
automatic change between portrait and landscape mode)
• 3 different tilt angles
• Built-In Optical Storage - DVD / CDRW Combo
• 3 USB 2.0 Ports Type A
• 1 Audio Line-Out; 1 Audio Mic Line-In
• 1 10/100 Ethernet port
• 1 Cradle/Docking Interface - 32 pin Connector
|
|
|
Scribbler 2000 / 2010
Scribbler Tablet PC is the
World’s Most Mobile Tablet PC with its full day
run time. Powered by our award winning battery, this Tablet PC gives
mobile users the ultimate tool. Running for upto 16 hours, the Scribbler
does not have to be managed. Simply turn it on in the morning and use it
all day. Much like your cell phone, your only concern is about your
productivity and not about your devices. Imagine the freedom provided
only by the Scribbler Tablet PC. No more AC adaptors, no more batteries
just full day productivity.
Main Features:
• Fast Intel Centrino 1.2 GHz processor to
ensure superior performance, efficiency and
power management
• Very bright 12.1inch screen
• Generous memory standard on both units (256MB
or 512 MB expandable)
• Integrated Infrared Port
• Integrated Biometric Device for Finger Print
Sensor
• Integrated IEEE 802.11b Wi-Fi wireless network
connectivity
• Pressure Sensitive Screen
• Convertible – comes with a detachable Keyboard
docking Station
• Sleek, thin, and lightweight design
• Extended battery life of up to 9 hours (70Wh)
Swappable battery
• Over $300 worth of software included
|
Scribbler Specifications: |
|
|
Processor
|
Intel Pentium – M ULV
Centrino |
|
CPU Speed |
1.2
GHz |
|
Chipset |
Intel
GMCH – M 855 GM chipset |
|
Graphics Chip Internal |
32MB
Intel 8285X GM/GME Graphics Controller |
|
PC Card Controller |
PCMCIA x 1 |
|
Audio |
Realtek AC’97 Audio |
|
System Storage |
Model 2000:
Toshiba 30 GB |
|
|
Model 2010:
Toshiba 40 GB |
|
System Memory |
Model 2000:
256 MB SODIMM |
|
|
Model 2010:
512 MB SODIMM |
|
Display |
12.1”
XGA TFT 32-bit color Toshiba |
|
Digitizer |
WACOM
PWB-A560-A |
|
Fingerprint Sensor |
AuthenTec AES3500 TruePrint Sensor |
|
Networking |
Built-in IEEE 802.11b, 10/100 Ethernet, 56K Modem |
|
Power Management |
Sleep
and Hibernation |
|
Power Mgmnt Modes |
ACPI
2.0 Compatible |
|
LED Indicators |
Power
On/Off Indicator, Battery Status, HDD Active, Wi-fi Connectivity |
|
External Connectors |
VGA
Out, IEEE1394, USB 2.0 x 2, Headphone Output x1, Microphone Input x
1, |
| |
AC/DC
Power Jack, RJ-11, RJ-45, Infrared SMC IrCC Fast port, Docking
Station port |
|
MIC |
Internal x 1 |
|
Speaker |
Internal x 2 |
|
Buttons |
Power
On/Off, Security, Start, Journal, Keyboard, Rotate, Esc, Function,
Wireless, Direction Ball + Enter |
|
Battery Pack |
Super
Polymer Lithium Ion 70 Whr |
|
Battery Charging Time |
5
hours 15 min ( Computer off mode) |
|
Dimension |
With
keyboard/mouse attached: 11.96” x 9.17” x 1.0” |
| |
Without keyboard/mouse attached: 11.96” x 9.16” x 0.75” |
|
Weight |
With
keyboard/mouse attached: 4.1 lbs |
| |
Without keyboard/mouse attached: 3.1 lbs |
|
Operating System |
Microsoft® Windows® XP Tablet PC Edition |
| |
|
|
Software Bundle: |
•
Corel Grafigo (Full Version)
• Adobe Acrobat reader 5.1 (Full Version)
• MacAfee virus scan 7.0
• Farstone Virtual drive lite (Full Version)
• Alias Sketchbook (Full Version)
• Note Taking
• Franklin Covey tablet planner (Trial Version)
• Ink Annotation
• MS Reader
• Speech Recognition
• On-screen Keyboard |
|
|
Advantage of the Scribbler
1. Four times longer battery life than any other Tablet PC.
2. The only Tablet PC on today’s market that can provide 10-16 hours of
run-time for a whole working day without charging the battery again.
3. The only Tablet PC that makes Microsoft’s Windows XP Tablet PC version
truly an operating system for mobile devices..
4. Highest battery Charge-time/Yield ratio
5. User replaceable battery
6. Professional 24/7 customer support.
Product comparison
|
|
Tablet
PC |
Desktop |
Notebook |
PDA |
|
Processing & Memory |
Strong |
Very
strong |
Strong |
Weak |
|
Writing
mobility |
Very
good |
Weak |
Good |
Very
good |
|
Communication |
Very
good |
Good |
Good |
Weak |
|
Pen-computing |
Very
good |
None |
Weak |
Good |
|
Viewing/Reading |
Very
good |
Good |
Good
|
Weak |
|
Voice
command |
Very
good |
Very
good |
Weak |
None |
|
Processor |
Ultra
Low Voltage Mobile Intel Pentium III Processor–M, SpeedStep Supported
|
|
CPU
Speed |
866
MHz |
|
Chipset |
Intel
830MG
|
|
Graphics Chip |
Internal: Intel 830MG External: Silicon Motion Lynx EM+ 730(Option)
|
|
Embedded Controller |
Hitachi H8 2149 |
|
PC
Card Controller |
Richo
(one PCMCIA, one CF, IEEE1394)
|
|
Audio |
Analog
Device AD1886
|
|
System
Storage |
30
GB, ODIMM user upgradeable Notebook type HDD |
|
System
Memory |
512MB
PC133 on board;
|
|
Display |
10.4"
XGA TFT, 16-bit colors
|
|
Digitizer |
Electromagnetic Digitizer
|
|
Networking |
Build-in IEEE802.11b, 10/100 Ethernet, V90 56K Modem |
|
Power
Management |
Deep
Sleep and Deeper Sleep
|
|
Management Modes |
ACPI
2.0 Compatible
|
|
LED
Indicators |
Power
On/Off Indicator, Battery Status, HDD Active |
|
External
|
External - Headphone Output x 1
|
|
Connectors |
Microphone Input x 1, AC/DC Power Jack, USB x 2, IEEE1394 x 1, PC Card
x 1 |
|
|
Compact Flash Card x1, Mini VGA x1 |
|
MIC |
Internal x 2
|
|
Speaker |
Speaker - Internal x 2
|
|
Buttons |
Power
On/Off, E-Mail Browser, landscape/Portrait Rotation, Display
Brightness
|
|
Battery Pack |
Battery Pack -4-cell Super Polymer Li-Ion Battery Pack |
|
Battery Charging Time |
5
hours (non-active), 6 hours (active)
|
|
Dimension |
275 x
223 x 30 mm ( 10.8" x 8.9" x 1.1" ) |
|
Weight |
1.79
kg ( 3.9 lb) |
|
Operating System |
Microsoft ® Windows® XP Tablet PC Edition |
|
|
