CA25T
Getac’s CA25T Tablet
PC is a full-featured, fully ruggedized tablet computer that
excels under harsh environments and weather conditions.
Wireless, light weight and encased in a die-cast magnesium
shell, the CA25T is Mil-Spec tested and certified for all field
conditions including use in transportation, shipping, warehouse,
import and export facilities, industrial field work and
facilities, utilities, emergency services and government
operations.
The CA25T features a hardened glass 10.4” touch screen to
protect the 10.4” display from the elements the digitizer
technology to enhance the original Touch Screen function. In
addition to its existing, lightweight, mobile, Mil-Spec
features, the CA25T has writing recognition and the various
Microsoft XP Table PC features.The CA25T includes Intel®
ultra–low voltage PentiumTM III 700 MHz processor, shock-mounted
Hard Drive, and Getac’s own unique X-Bay options. The X-Bay
supports Wireless LAN & CDPD modules, extra serial Ethernet and
IEEE Fire wire ports, and other customizable modules. Compliant
with Microsoft XP Tablet PC Edition.
FEATURES:
Tough 10.4” XGA Touch Screen
Microsoft Windows XP Tablet PC
Digitizer Technology Installed
Expandable X-Bay for Growth
|
After
visiting the following, click the back button
to return to this site.
|
|
CA25T
Specifications |
Processor |
|
•
Intel® Mobile Pentium® III 700MHz or above
• Celeron
500MHz or above
|
Cache |
|
•
256KB /128KB on die (depends on
processor type) |
BIOS |
|
•
Systemsoft flash BIOS |
Memory |
|
•
One 144 pins SO-DIMM for expansion
SDRAM module • Standard 128MB;
upgradeable up to 256MB
|
VGA |
|
•
32-bit PCI bus, 4MB video memory;
• Support
Dual-View function;
• LCD/CRT
simultaneous display capability;
|
Storage |
|
•
HDD: 2.5” 9.5mm height with shock
resistance bumper;
Standard: 10GB; Upgradeable to 30GB
• FDD:
Optional external USB 3.5” 1.44MB Floppy Disk
• Optional exteranl IDE
5.25” CD-ROM/ DVD-ROM module
|
Display |
|
•
Touch / Pen Input Screen(include
one stylus)
• 10.4” TFT
XGA (1024x 768) LCD
• Sunlight
Readable Panel (optional)
|
Panel |
|
•
Control Power On/off
• Audio
Volume Control-Battery status
• Brightness
Control
• Function
keys (F1, F2, F3)
|
Keyboard |
|
•
Wireless Keyboard with track
pad(optional)
• Wireless
Ruggedized Keyboard(optional)
|
PCMCIA |
|
•
One Type-II, ZV/CardBus support
|
I/O Port |
|
•
Serial port x 1
• USB port x
1
• DC input x
1
• IR port x
1, Complies with IrDA (FIR and SIR)
• RJ-11 x 1
for fixed internal modem module, PCI interface
• Wireless
K/B IR port
• Docking
port x 1
• CCD USB
port x 1
|
Battery |
|
•
Primary Li-lon Type Smart Battery
• 2nd
Battery(Optional)
|
Dimensions/
Weight |
|
•
11.7" x 9.4" x 1.7"(297mm x 238mm
x 44mm)
• 2.1 Kg(w/o
2nd battery)
|
Software |
|
•
Support Windows 98/Windows
NT4.0/Windows 2000/Windows XP Tablet PC edition |
X-Bay |
|
Multiple-choice Wireless
solution (LAN, CDPD, GSM);
Serial x 2 + IEEE 1394 x 1 port + LAN x1 port;
2nd Flash Disk |
|
Environmental Standards |
Temperature |
|
- IEC 68-2-1,2,14 /
MIL-STD-810F, Method 501.4, 502.4 Operating: 0°C to
55°C/32°F to 131°F
- Optional: -20°C to
55°C/-2°F to 131°F
Non-operating : -40°C to 70°C/-38°F to 158°F
|
Humidity |
|
- According to IEC 68-2-30
/ MIL-STD-810F,
Method 507.4
5% to 95% RH, non-condensing
|
Altitude |
|
- According to IEC 68-2-13
/ MIL-STD-810F,
Method 500.4
Operating: 15,000ft
Non-operating: 40,000ft
Altitude change rate: 2,000 ft/min
|
Shock |
|
- According to IEC 68-2-27
/ MIL-STD-810F,
Method 516.5
Operating: 15g/0.53 oz, 11 ms, half sine wave
Non-operating: 50g/1.76 oz, 11 ms, half sine wave
|
Vibration |
|
- According to IEC 68-2-6 /
MIL-STD-810F,
Method 514.5
Operating: 10~55Hz/0.075g, 55~500Hz/1.0g
Non-operating: 10~55Hz/0.15g, 55~500Hz/2.0g
- Highway truck vibration
exposure
|
Drop |
|
- According to IEC 68-2-32
/ MIL-STD-810F,
Method 516.5
3 Feet height free drop still survive, (test surface:
concrete, base unit only)
|
Enclosure |
|
- According to
MIL-STD-810F/IEC 529, NEMA
- Regulation FCC part 15,
Subpart B, Class B, UL, CUL, TUV, CE, CCC, WHQL, BSMI,
- MIL-STD-461E(option):
CE102; CS114, 115 & 116; RE102; RS103
- IP rating: A770-IP54;
W130-IP51; CA25T/CA27-IP52
|
|
Watch for
The CA27 - A
Rugged/Wireless Tablet PC Coming Soon
|

|
