PROCESSOR: Intel Mobile Pentiumฎ III-M Processor up
to 1.20 GHz
SYSTEM BUS SPEED: 133 MHz
L2 CACHE: 512K
MEMORY: 640MB SDRAM (Standard)
OPERATING SYSTEMS SUPPORTED
Windows XP Tablet PC Edition
CHASSIS CONSTRUCTION
Rugged, lightweight magnesium chassis
Custom-designed construction protects internal subsystems from shock
and vibration
SwitchIt 180บ hinge converts Laptop into Tablet
Removable handles
VIDEO MEMORY
User Selectable Shared Video RAM, 8MB to 48MB (Memory Dependent)
DRIVES OPTIONS
40GB Primary Removable Hard Drive (Standard - upgradeable to 60GB)
24X CD-ROM Drive Module- standard
I/O CONNECTORS
PCMICA Slots: Two Type II PCMCIA slots or One Type III
Audio Ports: Mic. In, Line Out, Speakers
One RJ11 (Modem 56k, V.90) port
One RJ45 10/100Mbs (Ethernet/LAN) port
Dual USB 2.0 Ports
Docking Connector
OTHER
Integrated 802.11b Wireless Local Area Network (WLAN) technology
Dual 1-Watt integrated, sealed stereo speakers
Omni-directional, integrated microphone
16-bit stereo audio subsystem
Carrying Shoulder Strap
KEYBOARD & MOUSE
Backlit sealed keyboard with full size sealed QWERTY keyboard with 84
keys (USA
Standard key set)
Sealed Mouse against weather, dust, and moisture (NEMA 3/ IP54)
Virtual keyboard
DISPLAY
12.1 1024 x 768 XGA resolution, 18-bit color
EMR Digitizer w/Stylus
One-touch brightness control
PHYSICAL CHARACTERISTICS
Weight: 8lbs with battery
Size (mm): 326W x 261D x 54H
Size (in): 12.8W x 10.25D x 2.125H
POWER SYSTEM
Power Management: On, Hibernate, Standby, Off
Software configurable power control button
57 Watt Lithium Ion Battery 3.5 hour life
AC Adapter: Input 90-264VAC, 50-60 Hz; Output: 12V, 55W
DC Input: 10V to 24V
12 DC Power Cord
12 AC Power Cord |
SYSTEM OPTIONS
I/O Extension Stick: Parallel, Serial, PS/2, RGB, USB 2.0 ports, Audio
ports Mic. In,
Line Out, Speakers
11-32 VDC Converter
International key sets (Spanish, French, German and others)
Soft Carrying Case
Hard Transit Case
Extra Lithium Ion Battery at 3.5-hours life
In-Vehicle Mount with or without Docking Station
LEFT BAY OPTIONS
40GB or 60GB Secondary Removable Hard Drive for front left bay
CD-RW Drive Module
DVD Drive Module
DVD/CD-RW Combo
ENVIRONMENTAL SPECIFICATIONS :
Temperature/Humidity Mil-Std-810F tested
Operating Temperature: -15บC to +50บC (5บF to 140บF)
Storage Temperature: -20บC to +70บC (-4บF to 158บF)
Operating Humidity: 10-88% relative humidity, non-condensing
Storage Humidity: 5-95% relative humidity, non-condensing
Rain and Dust P54 / NEMA 3
Shock
Mil-Std-810F, Method 516.5, Procedure I: 40G
Mil-Std-810F, Method 516.5, Procedure IV: 26 drops @ 48 (Transit
Case)
Designed For Raw Drop: 26 Drops @ 36 (No Transit Case)
Mil-Std-810F, Method 516.5, Procedure V: 75G
Vibration Mil-Std-810F, Method 514.5, Procedure I Category 20 & 24
EMI/EMC FCC Class B, CE Class B
Safety UL, cUL, CE
Altitude Mil-Std-810F, Method 500.4, Procedure I and II
Operational: 3,000 meters (10,000 feet)
Storage: 10,668 meters (35,000 feet) |
