Motion M1200

Motion Computing's entry into the Tablet PC field got a lot of attention at the Launch. The pure slate design along with its sleekly-designed docking station, well-balanced feel and futuristic-looking speakers drew admiring glances and lots of questions.  The Motion M1200 Tablet PC was one of only two models offering a 12.1" screen.

Along with more screen available for workspace, its lightweight design and efficient processor makes it an excellent choice for both workers who are always on the go as well as consumers who want top quality in their Tablet PC.

Since its launch, the Motion M1200 has been garnering awards from throughout the industry.

Motion Pure Tablet PC Designed to work the way you do!

The Motion is an ultra-mobile Tablet PC designed to work the way you do! Input, search, edit, highlight or find/replace in your current applications using a keyboard OR the pen. Take notes in meetings, enter client information or send an email. Your emails can even be sent in your own handwriting. With the built-in wireless feature, you can search the web, check for updates or sales information in your company database anywhere, anytime. Invite others into a private ad hoc network to discuss and edit a customized presentation online minutes before meeting with a client.

Your options are now endless. With all this functionality at less than 3 lbs. and sporting a rugged magnesium structure, you will want to take the Motion M1200 with you everywhere!

Introducing the first Pure Tablet PC
It's time for a revolution in the way people use computers. And Motion Computing is ready. A new company with deep technology roots, Motion Computing ’s sole mission is to improve the computing experience for mobile users. Our Pure Tablet PCs are designed to work the way you do — providing the industry’s best integration of ultra-mobile computing and Windows XP functionality.

Working the way you want
The M1200 Tablet PC from Motion Computing is an extension of your mind and your methods. It is designed from the ground up to adapt to your work style —not the other way around — for utmost ease of use. With one hand, you can dock or undock the Pure Tablet PC. Select different viewing modes, landscape or portrait.

And Motion makes a full line of accessories that are made for the way you work, including slim portfolio cases and desktop stands for ad hoc presentations.

Now, you can use your computer in the way that works best for you. The Motion M1200 Tablet PC enables you to create files and store information by simply writing directly on the screen with your Motion pen, typing with a keyboard or speaking into the microphone. You can use the Pure Tablet PC just as you would use a pad of paper and a pen —creating a completely natural writing experience. And the Motion pen also works like a mouse.

Enjoying Pure Tablet accessibility.
Motion's lightweight, ergonomic Pure Tablet design delivers maximum ease of use — in a PC the size of a spiral-bound pad of paper. Its spacious 12.1-inch screen is 35 percent larger than the 10.4-inch screen others offer. And its less than 1-inch thick dimensions make it comfortable to hold and use. Perfectly balanced, there is no unwieldy clamshell design —or hinges to wear out.

Business today occurs far beyond the walls of the typical office. The workforce is increasingly mobile. And these employees require tools that can adapt to the rapidly changing digital workplace.

While notebook computers and handheld devices are more popular than ever, they only offer a stepping-stone to mobile computing. Handhelds are not powerful enough to be true, multi-function computers, and traditional "clamshell" notebooks are not practical for any mobile users —since the devices cannot be used while walking or standing, and often weigh more than four pounds. As a result, mobile users have been forced to rely on an awkward combination of desktop PCs, notebooks, handhelds and pen devices to complete their work. There ’s been no single, powerful tool for being as productive as possible when away from one ’s desk.

Until now. Enter the Tablet PC. This new type of computer puts the full features of Microsoft® Windows® XP Tablet PC Edition in a portable device, along with pen and speech capabilities. So employees can bring the power of the PC into more places than ever.


Specifications - Motion M1200
Chassis • Magnesium Alloy
Processor • Mobile Intel® Pentium® III
Processor-M, ULV 933MHz
Chipset • Intel 830MG
Display • 12.1" XGA TFT LCD
Graphics • Intel 830MG integrated
UMA graphics card
• Rotation 0°, 90°, 180°, 270°
PC Card Controller • OZ6912 PCI Cardbus Controller
Audio • AC 97 audio codec
System Memory • Base RAM of 256MB or 512MB
• One expansion SODiMM-memory slot for a PC133 module
• Maximum 1GB (512MB x 2)
System Storage • 2.5" Hard Disk Drive (HDD) with up to 60GB capacity
• PCI bus master enhanced IDE
• Supports Ultra DMA 66/100
Communications • Integrated 10/100 LAN controller
• Soft modem with V.92 interface;
56.6Kbps/14.4Kbps transceiver fax
• IEEE 802.11b Wireless LAN via Mini PCI interface with integrated antennas
Input Devices • Active digitizer pen (no battery required)
• Integrated microphone
Speakers • Integrated speakers
I/O Ports • Microphone In
• Headphone Out
• DC Power In
• Two USB 1.1 Ports
• External VGA
• IEEE 1394
• RJ-11 and RJ-45
• Docking connector
PCMCIA • Type II slot
Dimensions • 11.65" x 9.45" x .87"
(296mm x 240mm x 22mm)
Weight • Less than 3 lbs*
Operating System • Microsoft® Windows® XP Tablet PC Edition
Battery • 6-cell, prismatic Li-ion battery
• 40WHr capacity
• Optional, lightweight, 3-cell prismatic Li-ion battery
Battery Charging • Approximate charging time:
Time - 2 hours (Tablet PC ON)
 1.2 hours (Tablet PC OFF)
System Status • Power On/Off
LEDs • Battery Status
• Hard Disk Drive (HDD) activity
• Wireless On/Off
Control Buttons • Power
• Portrait/Landscape orientation
• Four function buttons
• One 5-way directional button
AC Adapter • 50W universal, 2-pin jack
• 90~264V AC, 47~63Hz
BIOS • 512KB Flash BIOS ROM
• Suspend to RAM
• Suspend to Disk
• Password protection for system
• ACPI 1.1 compliant
• Pen/Button-driven setup
Environmental • Temperature
. Operation: +5°C to +35°C
. Storage: -20°C to +65°C
• Humidity
. 10% to 90% without condensation
• Altitude
. Operation: sea level 0 to 10K ft.
. Storage: sea level 0 to 40K ft.
Standards • PC2001 logo compliant
• ACPI Revision 1.0b
Regulatory • EMI: FCC Part 15 Class B
• Safety: Compliant to UL/CSA
• FCC Part 68: CCEE PTT
Warranty • 1-year limited warranty
• Extended warranty available
ACCESSORIES

DOCKING SOLUTIONS

Motion Computing’s docking solutions are the perfect way to extend the use of your Motion Tablet PC and operate it as a full-featured desktop PC. Our docking solutions support one-handed, hot "grab-and-go "docking/undocking, allowing you to quickly remove or insert the M1200 or M1300 while it is running.

M-Series FlexDock

Use your M1200 or M1300 like a desktop computer. Unique design supports multiple viewing angles in portrait or landscape orientation. The FlexDock comes with three USB ports, 1394/FireWire and RJ45 Ethernet connections, speaker and microphone jacks and a VGA port. Part number:301-050-01

M-Series Desktop Stand

Great for presentations and travel, the M-Series Desktop Stand allows you to use your Motion Tablet PC like a desktop computer and provides a convenient way to conduct small, intimate presentations anywhere.  Part number:501-450-01

CASES AND PORTFOLIOS

Motion Computing ’s full line of cases and portfolios support a wide range of uses and functionality —while protecting your investment.

M-Series Executive Portfolio

Crafted from high-quality leather, the Executive Portfolio includes a shoulder strap for maximum portability. Includes pen and business card holders, as well as a paper pocket. Part number:501-400-02

M-Series Standard Portfolio

The perfect companion for your Motion Tablet PC,the Standard Portfolio is constructed from strong, lightweight materials and includes a shoulder strap. The hand strap allows you to hold the unit securely while in use.  Part number:501-400-01

M-Series Hard Top Cover

Provide protection for your display. The lightweight cover snaps in place and can be stored on the bottom of the unit for added convenience. Part number:501-400-03

M-Series Slip Case

Ideal for field work, the Slip Case has a clear window so you can use your Motion Tablet PC while protecting it from the elements. Built from durable neoprene, the form-fitted case includes a hand strap for easy handling. Part number:501-400-04

INPUT DEVICES

Motion Computing offers a variety of input devices, including our unique Mobile Keyboard with Touchpad, to make your M1200 even easier to use.

M-Series Mobile Keyboard with Touchpad

This trim keyboard comes with 88 keys and an integrated touchpad and is designed to meet the needs of both mobile and desktop users. Part number:501-550-01

M-Series Digitizer Pen

This innovative, full-size pen works with your M1200 and includes a "right-mouse-click "button. Replaceable pen tips included. Part number 501-500-01  Three packs also available.  Part number (3 pack):501-500-03

For General Inquiries: info@motioncomputing.com

For Sales Information: sales@motioncomputing.com

For Partner Inquiries: partners@motioncomputing.com

Motion Computing M1200 Tablet PC Wins Planet PDA 2002 Product of the Year Award

AUSTIN, Texas, Feb. 26, 2003 – Motion Computing today announced that its M1200 Tablet PC has won a Planet PDA® Product of the Year Award for 2002. Produced by Technology Marketing Corp. (TMC), Planet PDA Magazine is a daily Web site that provides managers with information about incorporating mobile devices into their computing infrastructure. Each year, Planet PDA awards a variety of products and services that drive the handheld computing field.

"Motion Computing has played an important role in creating a new category of computing products with the Tablet PC," said Rich Tehrani, president of TMC and group editor-in-chief of Planet PDA®.  We're proud to recognize their hard work and innovation with a Product of the Year Award for 2002."

For the full story, click here

For more news stories about Motion Computing, check http://thetabletpc.net/news.htm

For information on current models of Motion Tablet PCs, click here
