Actius TN 10W

Hybrid Tablet and
Notebook Computer with integrated wireless network
Combining the Tablet PC solution with the latest mobile computing
technology, the Actius TN10W gives you the best mobility and
functionality at any time, any place.
The
Actius TN10W can be comfortably operated by converting the screen to
tablet mode and with the use of a digital pen. It's just like taking
notes on a tablet of paper. |
Powered by the latest Intel Mobile Pentium M 1.1GHz processor with Intel
Centrino Technology, the Actius TN10W provides you superb performance,
wireless connectivity and long battery life. With the ability to convert
to three modes of operation, the productivity-enhancing Actius TN10W is
ideal for the highly mobile user. Intel® Centrino™ Mobile T echnology
allows the Actius TN10W outstanding capability. With its Intel® Pentium®
M 1.1GHz processor, 12 .1" XGA TFT LCD screen, 256MB of RAM (user
expandable up to 768MB), 30GB hard drive and Intel PRO Wireless Network
Connection 802.11b, the Actius TN10W establishes new standards for
usability and performance.
Versatile Mobile
Computing
Equipped with a large, 12.1" LCD screen that can be rotated 180 degrees,
the Actius TN10W has the ability to convert to three different modes of
operation: Notebook mode for typical office use, Tablet mode utilizing
pen operation for note-taking and computing while on the move, and
Presentation mode for face to face presentations in small groups. In
Tablet mode, data can be
input via a virtual keyboard on the display or written with a digital
pen. Your handwriting can be saved as it is written or converted to
text. In addition, the Actius TN10W can be switched from portrait mode
to landscape mode with a single button. Using a notebook computer has
never been easier.
Intel® Centrino™
Mobile Technology
The
Actius TN10W features the new Intel® Centrino™ Mobile technology
incorporating the Intel® Pentium® M Processor 1.1GHz, Intel® PRO
Wireless Network Connection 802.11b and Intel® 855GM chipset. This
advanced technology contributes to the outstanding performance and
excellent approx. 5.0 hours battery life of the Actius TN10W.
|
Specifications
Technology |
Intel® Centrino™ Mobile Technology |
|
PCMCIA |
Type II x 1, CardBus supported |
CPU |
LV Intel® Pentium® M 1.1GHz |
CF Card Slot |
Type II x 1 |
Memory |
256MB DDR SDRAM standard, expandable to 768MB |
Audio System |
AC97 compatible, built-in monaural speaker |
Video Controller |
Integrated in chipset |
I/O Ports |
USB (2.0) x 2, IEEE1394, LAN, modem, Audio output, Mic
in, VGA, DC in |
VRAM |
VRAM Max. 64MB (Intel® Dynamic Video Memory Technology <DVMT>) |
LAN |
Wireless (IEEE802.11b), 100Base-TX/10Base-T |
Display |
12.1" XGA TFT LCD (1024 x 768), 16 million colors |
Modem |
56kbps fax/modem (v.90) |
Hard Drive |
Approx. 25GB (Total 30GB. 5GB reserved for recovery
image) |
AC Adapter |
Universal AC adapter -Input: 100.240V, 50/60Hz AC |
Optical Drive |
External Option |
Battery |
Rechargeable lithium-ion battery |
Pointing Device |
Glide Pad (touch-sensitive control pad), Intelli-Wheel
feature |
Battery Life |
Standard battery only: approx.
5.0 hrs* |
Digitizer |
ElectroMagnetic Digitizer |
Dimensions |
(W x D x H) 11.4" x 9.0" (min.)/10.1" (max.) x 1.13" |
Keyboard |
Approx. 18 mm key pitch / 2 mm stroke keyboard |
Weight |
approx. 4.2lbs (approx. 1.9kg) |
Operating Environment |
Temperature : 50˚F t o 95˚F (10˚C t o 35˚C)
Humidity: 20% to 80% (non-condensation)
Power Consumption Max. 40 W |
Operating System |
Microsoft® Windows® XP Tablet PC Edition** |
|
|
Software |
Network setup utility, Adobe® Acrobat® Reader® |
|
As
an ENERGY STAR® Partner, SHARP has determined that this product meets
the ENERGY STAR® guidelines for energy efficiency.
|

|
